Feature Of High Speed Intelligent Plush Fabric Raschel Machine

  • High speed plush fabric warp knitting machine uses an oil immersed cam-linkage mechanism and fixed ground bars;
  • Raschel warp knitting machine utilizes ear-lowering pieces and wire guards to prevent breakage during fabric insertion;
  • The yarn let-off device controls the 2 rollers for positive yarn feeding;
  • The plush has a pile height of 3.5-25mm.

Raschel Warp Knitting Machine

  • Single Needle Bar Raschel Warp Knitting Machine
    The single needle bar Raschel warp knitting machine is mainly used for producing single-sided fabrics, ideal for fast production of elastic and rigid garments, intimate apparel and lingerie fabrics, and more.
  • Double Needle Bar Raschel Warp Knitting Machine
    The double needle bar Raschel warp knitting machine allows independent weaving on two parallel and back-to-back needle bars. This enables the production of patterns and fabrics different from those produced by single needle bar machines, either through partial or complete connection. It is particularly suitable for weaving replacement fabrics and medium to heavy-weight fabrics, such as spacer fabrics, plush fabrics, seamless products, and air mesh fabric.

    Application Of Warp Knitting Machines

    This machine is specially developed for producing apparel fabric, plush toy, home textile and upholstery fabric, etc.

    application of high speed intelligent plush fabric raschel machine

    Application Of Intelligent Plush Fabric Raschel Machine

    Application Of Raschel Warp Knitting Machine

    Technical Data Of Intelligent Plush Fabric Raschel Machine

    Needle Type: individual latch needle, block needle

    Gauge: E18, E22

    Number Of Bars: 5 bars

    Working Width: 90”, 100”, 110”, 138″, 150″, 158”, 170”, 184”, 210″

    Max. speed: 950rpm
